Rev. 5.00, 09/03, page 743 of 760
Control Register Module
*
1
Bus
*
2
Address
*
4
Size (Bits) Access Size (Bits)
*
3
ADDRCL A/D P 400008A 8 8,16
*
5
ADDRDH A/D P 400008C 8 8,16,32
*
5
*
6
ADDRDL A/D P 400008E 8 8,16
*
5
ADCSR A/D P 4000090 8 8,16,32
*
5
*
6
ADCR A/D P 4000092 8 8,16
DADR0 D/A P 40000A0 8 8,16,32
*
5
*
6
DADR1 D/A P 40000A2 8 8,16
*
5
DACR D/A P 40000A4 8 8,16,32
PACR PORT P 4000100 16 16
PBCR PORT P 4000102 16 16
PCCR PORT P 4000104 16 16
PDCR PORT P 4000106 16 16
PECR PORT P 4000108 16 16
PFCR PORT P 400010A 16 16
PGCR PORT P 400010C 16 16
PHCR PORT P 400010E 16 16
PJCR PORT P 4000110 16 16
PKCR PORT P 4000112 16 16
PLCR PORT P 4000114 16 16
SCPCR PORT P 4000116 16 16
PADR PORT P 4000120 8 8
PBDR PORT P 4000122 8 8
PCDR PORT P 4000124 8 8
PDDR PORT P 4000126 8 8
PEDR PORT P 4000128 8 8
PFDR PORT P 400012A 8 8
PGDR PORT P 400012C 8 8
PHDR PORT P 400012E 8 8
PJDR PORT P 4000130 8 8
PKDR PORT P 4000132 8 8
PLDR PORT P 4000134 8 8
SCPDR PORT P 4000136 8 8
