Control Register Module
*
1
Bus
*
2
Address
*
4
Size (Bits) Access Size (Bits)
*
3
RWKAR RTC P FFFFFED6 8 8
RDAYAR RTC P FFFFFED8 8 8
RMONAR RTC P FFFFFEDA 8 8
RCR1 RTC P FFFFFEDC 8 8
RCR2 RTC P FFFFFEDE 8 8
ICR0 INTC I FFFFFEE0 16 16
IPRA INTC I FFFFFEE2 16 16
IPRB INTC I FFFFFEE4 16 16
TOCR TMU P FFFFFE90 8 8
TSTR TMU P FFFFFE92 8 8
TCOR0 TMU P FFFFFE94 32 32
TCNT0 TMU P FFFFFE98 32 32
TCR0 TMU P FFFFFE9C 16 16
TCOR1 TMU P FFFFFEA0 32 32
TCNT1 TMU P FFFFFEA4 32 32
TCR1 TMU P FFFFFEA8 16 16
TCOR2 TMU P FFFFFEAC 32 32
TCNT2 TMU P FFFFFEB0 32 32
TCR2 TMU P FFFFFEB4 16 16
TCPR2 TMU P FFFFFEB8 32 32
SCSMR SCI P FFFFFE80 8 8
SCBRR SCI P FFFFFE82 8 8
SCSCR SCI P FFFFFE84 8 8
SCTDR SCI P FFFFFE86 8 8
SCSSR SCI P FFFFFE88 8 8
SCRDR SCI P FFFFFE8A 8 8
SCSCMR SCI P FFFFFE8C 8 8
INTEVT2 INTC I 4000000 32 32
IRR0 INTC I 4000004 16 8
IRR1 INTC I 4000006 16 8
IRR2 INTC I 4000008 16 8
