Rev. 5.00, 09/03, page 576 of 760
18.3.7 Port G Control Register (PGCR)
Bit: 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PG7
MD1
PG7
MD0
PG6
MD1
PG6
MD0
PG5
MD1
PG5
MD0
PG4
MD1
PG4
MD0
PG3
MD1
PG3
MD0
PG2
MD1
PG2
MD0
PG1
MD1
PG1
MD0
PG0
MD1
PG0
MD0
Initial value:1 0 1 01/00 1 01/001/001/001/00
R/W: R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
The port G control register (PGCR) is a 16-bit readable/writable register that selects the pin
functions. PGCR is initialized to H'AAAA (ASEMD0 = 1) or H'A200 (ASEMD0 = 0) by a power-
on reset, but is not initialized by a manual reset, in standby mode, or in sleep mode.
Bits 15 and 14—PG7 Mode 1 and 0 (PG7MD1, PG7MD0)
Bits 13 and 12—PG6 Mode 1 and 0 (PG6MD1, PG6MD0)
Bits 11 and 10—PG5 Mode 1 and 0 (PG5MD1, PG5MD0)
Bits 9 and 8—PG4 Mode 1 and 0 (PG4MD1, PG4MD0)
Bits 7 and 6—PG3 Mode 1 and 0 (PG3MD1, PG3MD0)
Bits 5 and 4—PG2 Mode 1 and 0 (PG2MD1, PG2MD0)
Bits 3 and 2—PG1 Mode 1 and 0 (PG1MD1, PG1MD0)
Bits 1 and 0—PG0 Mode 1 and 0 (PG0MD1, PG0MD0)
These bits select the pin functions and perform input pull-up MOS control.
