Rev. 5.00, 09/03, page 126 of 760
Table 6.4 Interrupt Exception Handling Sources and Priority (IRQ Mode)
Interrupt Source
INTEVT Code
(INTEVT2 Code)
Interrupt
Priority
(Initial Value)
IPR (Bit
Numbers)
Priority
within IPR
Setting Unit
Default
Priority
NMI H'1C0 (H'1C0) 16 — — High
UDI H'5E0 (H'5E0) 15 — —
IRQ IRQ0 H'200–3C0
*
(H'600) 0–15 (0) IPRC (3–0) —
IRQ1 H'200–3C0
*
(H'620) 0–15 (0) IPRC (7–4) —
IRQ2 H'200–3C0
*
(H'640) 0–15 (0) IPRC (11–8) —
IRQ3 H'200–3C0
*
(H'660) 0–15 (0) IPRC (15–12) —
IRQ4 H'200–3C0
*
(H'680) 0–15 (0) IPRD (3–0) —
IRQ5 H'200–3C0
*
(H'6A0) 0–15 (0) IPRD (7–4) —
PINT PINT0–7 H'200–3C0
*
(H'700) 0–15 (0) IPRD (15–12) —
PINT8–15 H'200–3C0
*
(H'720) 0–15 (0) IPRD (11–8) —
DMAC DEI0 H'200–3C0
*
(H'800) 0–15 (0) IPRE (15–12) High
DEI1 H'200–3C0
*
(H'820)
DEI2 H'200–3C0
*
(H'840)
DEI3 H'200–3C0
*
(H'860) Low
IrDA ERI1 H'200–3C0
*
(H'880) 0–15 (0) IPRE (11–8) High
RXI1 H'200–3C0
*
(H'8A0)
BRI1 H'200–3C0
*
(H'8C0)
TXI1 H'200–3C0
*
(H'8E0) Low
SCIF ERI2 H'200–3C0
*
(H'900) 0–15 (0) IPRE (7–4) High
RXI2 H'200–3C0
*
(H'920)
BRI2 H'200–3C0
*
(H'940)
TXI2 H'200–3C0
*
(H'960) Low
ADC ADI H'200–3C0
*
(H'980) 0–15 (0) IPRE (3–0) —
TMU0 TUNI0 H'400 (H'400) 0–15 (0) IPRA (15–12) —
TMU1 TUNI1 H'420 (H'420) 0–15 (0) IPRA (11–8) —
TMU2 TUNI2 H'440 (H'440) 0–15 (0) IPRA (7–4) High
TICPI2 H'460 (H'460) Low Low
