Chapter 5 197
Language Reference
CALCulate Subsystem
Example: To query the mean power of a set of GSM bursts:
1. Set the waveform measurement sweep time to
acquire at least one burst.
2. Set the triggers such that acquisition happens at a
known position relative to a burst.
3. Then query the mean burst levels using,
CALC:DATA2:COMP? MEAN,24e-6,526e-6 (These
parameter values correspond to GSM signals, where
526e-6 is the length of the burst in the slot and you
just want 1 burst.)
NOTE There is a more detailed example in the Improving the Speed of Your
Measurements section in the E4406A programmers guide.
Remarks: The optional parameters must be entered in the
specified order. For example, if you want to specify
<length>, you must also specify <soffset>.
This command uses the data in the format specified by
FORMat:DATA, returning either binary or ASCII data.
History: Added in revision A.03.00
Changed in revision A.05.00
Measurement Available Traces Markers
Available?
ACP - adjacent channel power
(Basic, cdmaOne, cdma2000, W-CDMA
(3GPP), iDEN, NADC, PDC modes)
no traces no markers
BER - bit error rate
(iDEN mode)
no traces no markers
CDPower - code domain power
(cdmaOne mode)
POWer (n=2)
a
TIMing (n=3)
a
PHASe (n=4)
a
yes
CDPower - code domain power
(cdma2000, W-CDMA (3GPP) modes)
CDPower (n=2)
a
EVM (n=5)
a
MERRor (n=6)
a
PERRor (n=7)
a
SPOWer (n=9)
a
CPOWer (n=10)
a
yes
