Configuration and Use Manual 69
Using the Filling and Dosing Application
Optional Configuration Using the FillerFiller ConfigurationUsing the Transmitter Optional Configuration Using the FillerFiller ConfigurationUsing the Transmitter Optional Configuration Using the FillerFiller ConfigurationUsing the Transmitter Optional Configuration Using the FillerFiller ConfigurationUsing the Transmitter
Table 8-1 Run Filler displays and controls
Display/Control Description
Fill Setup Current Total Displays the running fill total, updated periodically, for the current fill.
This value is not updated between fills. However, if flow is present while a fill is
paused, the value is updated.
Reset Fill Total Resets the fill total to 0.
Current Target Displays the target quantity for the current fill.
• To change this value, enter the new target value and click Apply.
• You cannot change the target while a fill is in progress, unless the fill is
paused.
AOC Coeff Displays the factor used to adjust the target, if AOC is enabled.
(1)
• To change this value, enter the new AOC value and click Apply. WARNING:
Writing to this parameter will overwrite any existing AOC calibration results.
• You cannot change the AOC coefficient while a fill is in progress, whether the
fill is currently flowing or is paused.
Fill Control Begin Filling Starts the fill.
The fill total is automatically reset before filling begins.
Pause Filling Temporarily stops the fill.
The fill can be resumed if the fill total is less than the fill target.
Resume Filling Restarts a fill that has been paused.
Counting resumes from the total at which the fill was paused.
End Filling Permanently stops the fill or purge.
The fill cannot be resumed.
Begin Purge Begins a manual purge by opening the secondary valve.
You cannot begin a purge while a fill is in progress.
You cannot begin a fill while a purge is in progress.
End Purge Ends a manual purge by closing the secondary valve.
Begin Cleaning Opens all valves (except purge valve) that are assigned to a transmitter output.
Cleaning cannot be started if a fill or purge is in progress.
End Cleaning Closes all valves that are assigned to a transmitter output.
AOC
Calibration
Start AOC Cal Begins AOC calibration.
Save AOC Cal Ends AOC calibration and saves the calculated AOC coefficient.
Override Blocked Start Enables filling if the fill has been blocked by:
•Slug flow
• A core processor fault
• The last measured flow rate is too high, as indicated by the corresponding
status LED (see Table 8-2).
Reset AOC Flow
Rate
(2)
Resets the last measured flow rate to zero, to bypass the condition indicated by
the AOC Flow Rate Too High status LED (see Table 8-2).
If the flow rate is too high, and this is not a one-time condition:
• And you are using standard AOC calibration, try resetting the AOC flow rate
(see below). If this does not clear the condition, repeat AOC calibration.
• And you are using rolling AOC calibration, overriding the blocked start once or
twice should correct the condition.
