Model 1500 Transmitters with the Filling and Dosing Application
Required Transmitter Configuration
4.4 Configuring the measurement units
For each process variable, the transmitter must be configured to use the measurement unit appropriate
to your application.
To configure measurement units, see the menu flowchart in Figure 4-6. For details on measurement
units for each process variable, see Sections 4.4.1 through 4.4.5.
Figure 4-6 Configuring measurement units
4.4.1 Mass flow units
The default mass flow measurement unit is
g/s. See Table 4-3 for a complete list of mass flow
measurement units.
If the mass flow unit you want to use is not listed, you can define a special measurement unit for mass
flow (see Section 6.4).
Table 4-3 Mass flow measurement units
ProLink II label Unit description
g/s Grams per second
g/min Grams per minute
g/hr Grams per hour
kg/s Kilograms per second
kg/min Kilograms per minute
kg/hr Kilograms per hour
kg/day Kilograms per day
mTon/min Metric tons per minute
mTon/hr Metric tons per hour
mTon/day Metric tons per day
lbs/s Pounds per second
lbs/min Pounds per minute
lbs/hr Pounds per hour
lbs/day Pounds per day
sTon/min Short tons (2000 pounds) per minute
sTon/hr Short tons (2000 pounds) per hour
sTon/day Short tons (2000 pounds) per day
Configuration
ProLink Menu
Density
· Dens units
Flow
· Mass flow units
· Vol flow units
Temperature
· Temp units
Pressure
· Pressure units
