Appendix
— Reference Guide Appendix–47
Region edit Erase, delete, copy, move, time compression/
expansion, pitch change, insert
Others
Locate Direct locate: data entry search (time, measure)
Quick locate: start, end, RTZ, A/B, last rec in/
out, roll back
Punch I/O Manual punch I/O, auto punch I/O
Controls
Analog section
Input (channel 1–8) Gain (variable)
Input (channel 1, 2) +48 V (phantom switch)
Output Phones level, monitor out level
Mixer section
WORK NAVIGATE buttons SONG, QUICK REC, MASTERING, CD PLAY
UNIT buttons SETUP, FILE, UTILITY, MIDI
MIXER buttons VIEW, PAN, EQ, DYN
FADER MODE buttons AUX1, AUX2, AUX3, AUX4, AUX5, AUX6,
AUX7, AUX8, HOME
MIXING LAYER buttons 1–16, 17–24 RTN, MONI
ON buttons, SEL buttons, Faders
1–8 channel 1–8, channel 17–24
9–14 channel 9–14
15 channel 15/return1
16 channel 16/return 2
17 stereo master
SOLO buttons
Function buttons SHIFT × 2, F1, F2, F3, F4, F5
EQ buttons HIGH, HI-MID, LO-MID, LOW
Encoders PAN, Q, F, G
Sampler section
SAMPLING PAD buttons 1, 2, 3, 4, 5, 6, 7, 8, BANK, EDIT
Recorder section
CUE button
REC TRACK SELECT buttons 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15,
16, ST, ALL, SAFE
RECORDER buttons TRACK, EDIT
Locate buttons NUM LOCATE, , , MARK, AUTO PUNCH,
IN, OUT, SET, REPEAT, A, B, ROLL BACK, ,
RTZ, , CANCEL
Transport buttons REW, FF, STOP, PLAY, REC
