Appendix
Appendix–10 — Reference Guide
MOD.DELAY
Basic repeat delay with modulation.
DELAY LCR
Three-tap delay (left, center, right).
ECHO
Stereo delay with crossed feedback loop.
Parameter Range Description
DELAY 0.0–2725.0 ms Delay time
FB.GAIN –99 to +99%
Feedback gain (plus values for normal-phase feedback, minus values
for reverse-phase feedback)
HI.RATIO 0.1–1.0 High-frequency feedback ratio
FREQ. 0.05–40.00 Hz Modulation speed
DEPTH 0–100% Modulation depth
HPF Thru, 21 Hz–8.0 kHz High-pass filter cutoff frequency
LPF 50 Hz–16.0 kHz, Thru Low-pass filter cutoff frequency
MIX BAL. 0–100 [%] Mix balance of the effects and dry sounds
Parameter Range Description
DELAY L 0.0–2730.0 ms Left channel delay time
DELAY C 0.0–2730.0 ms Center channel delay time
DELAY R 0.0–2730.0 ms Right channel delay time
LEVEL L –100 to +100% Left channel delay level
LEVEL C –100 to +100% Center channel delay level
LEVEL R –100 to +100% Right channel delay level
FB.DLY 0.0–2730.0 ms Feedback delay time
FB.GAIN –99 to +99%
Feedback gain (plus values for normal-phase feedback, minus values
for reverse-phase feedback)
HI.RATIO 0.1–1.0 High-frequency feedback ratio
HPF Thru, 21 Hz–8.0 kHz High-pass filter cutoff frequency
LPF 50 Hz–16.0 kHz, Thru Low-pass filter cutoff frequency
MIX BAL. 0–100 [%] Mix balance of the effects and dry sounds
Parameter Range Description
DELAY L 0.0–1350.0 ms Left channel delay time
FB.DLY L 0.0–1350.0 ms Left channel feedback delay time
FB.G L –99 to +99%
Left channel feedback gain (plus values for normal-phase feedback,
minus values for reverse-phase feedback)
DELAY R 0.0–1350.0 ms Right channel delay time
FB.DLY R 0.0–1350.0 ms Right channel feedback delay time
FB.G R –99 to +99%
Right channel feedback gain (plus values for normal-phase feedback,
minus values for reverse-phase feedback)
L->R FBG –99 to +99%
Left to right channel feedback gain (plus values for normal-phase
feedback, minus values for reverse-phase feedback)
R->L FBG –99 to +99%
Right to left channel feedback gain (plus values for normal-phase
feedback, minus values for reverse-phase feedback)
HI.RATIO 0.1–1.0 High-frequency feedback ratio
HPF Thru, 21 Hz–8.0 kHz High-pass filter cutoff frequency
LPF 50 Hz–16.0 kHz, Thru Low-pass filter cutoff frequency
MIX BAL. 0–100 [%] Mix balance of the effects and dry sounds
