5. Lenses & lens holder
5.4 Lens removal
How to remove a lens from the projector lens holder ?
1. Support the lens with one hand while you unlock the lens holder by sliding the lock handle towards the “unlocked” position as
illustrated.
Image 5-4
2. Gently pull the lens out of the lens holder.
Image 5-5
It’s recommended to place the lens caps of the original lens packaging, back on both sides of the removed
lens to protect the lens.
It’s recommended to place the foam rubber of the original projector packaging, back in the lens opening to
prevent intrusion of dust. Note that this foam rubber is packed in a plastic bag to prevent the dust, emitted by
the foam, from entering the projector.
R59770091 DP-1500 06/01/2009 37
