A. Specifications
A.1 Specifications of the DP-1500
Specifi cations
Ambient Temperature
max. 35°C / 95°F
Contrast ratio
2000:1
Digital MicroMirror Device™
3 x 0.98" DC2K dark metal devices
Digital Video Inputs
2 x SMPTE 292M inputs
2 x DVI input
both selectable as s ingle or as dual link
Dimensions Projector:
505(H) x 689(W) x 1018(D) mm
19.9(H) x 27.1(W) x 40.0(D) inch
NB.: min. 5 cm of air inlet spacing required at the bottom of projector
Housing Hermetically sealed DMD™ and optical assembly
Lamp
1.5kW - 3kW Xenon lamp size
Lamp power:
1.5kW - 3kW
Mounting
universal pedestal (optional)
Native resolution 2048 x 1080
Options CLO-constant light output
ACS-2048
SNMP agent
motorized/memorized lens focus, zoom & shift
automatic XYZ lamp alignm ent
Order Information R9004443
Power Requirements 220V
14.000 BTU / hr (with 3kW lamp)
Prime Lenses
Prime lens (1.2 - 1.8) 0.98" DC2K
Prime lens (1.4 - 2.05) 0.98" DC2K
Prime lens (1.6 - 2.5) 0.98" DC2K
Prime lens (1.95 - 3.2) 0.98" DC2K
Prime lens (2.4 - 3.9) 0.98" DC2K
Projector Diagnostics
via PC touch panel
via Communicator c ontrol software
via SNMP agent
Screen Width Screen width (screen gain 1:5) @ 14ftL * : 15m - 50ft
Screen width (screen gain 1:3) @ 14ftL * : 14m - 45ft
(*) = +/- 10 variation possible between units
Weight projector: 90k g (199lbs)
R59770091 DP-1500 06/01/2009 141
