X4& = Input signal/SDI genlock
0 = Disabled; (default)
1 = Input signal genlock enabled; locks output vertical to the selected input vertical rate
2 = SDI genlock enabled; locks output vertical to the applied genlock input (“D” models only)
X4* = Input signal/genlock status
0 = Input signal / SDI genlock disabled
1 = Input signal / SDI genlock enabled, but cannot lock to applied input signal/SDI genlock
input. DVS defaults to set output rate/refresh
2 = Input signal/SDI genlock enabled, output locked to applied input signal/SDI genlock input
X4( = Input HDCP HDMI authorization status:
0 = Block HDCP encryption
1 = Allow HDCP encryption (default for inputs 3, 4, and 5)
X5) = Horizontal genlock offset: range is ± the correct output resolution total pixel value -1
(for example, -2199 to +2199 for 1080p)
X5! = Vertical genlock offset: range is ± the correct output resolution total line value -1
(for example, -1124 to +1124 for 1080p)
SIS IP command definitions
X10) = Default name: combination of model name and last 3 hex pairs of MAC address
(for example DVS-605-Series-07-8C-EC).
X10$ = On/off status: 0 = off/disable; 1 = on/enable
X10^ = Unit name is a text string up to 24 characters drawn from the alphabet (A-Z), digits (0-9),
minus sign/hyphen (-). No blank or space characters are permitted as part of a name.
No distinction is made between upper and lower case. The first character must be an alpha
character. The last character must not be a minus sign/hyphen.
X10& = Local date and time format
Set format is MM/DD/YY-HH:MM:SS; for example, 06/21/02-10:54:00
Read format is day, date month year (HH:MM:SS), for example, Thu, 20 Feb 2003 (18:19:33)
X10* = IP address (xxx.xxx.xxx.xxx); leading zeros in each of 4 fields are optional in setting
values, and are suppressed in returned values.
NOTE: DHCP is disabled by default. Default IP is 192.168.254.254.
X10( = Hardware (MAC) address (00-05-A6-xx-xx-xx).
X11) = Subnet mask (xxx.xxx.xxx.xxx). Leading zeros are optional in setting values in each of four
fields, and are suppressed in returned values. Default subnet mask = 255.255.0.0
X11! = Verbose/Response mode, (default = 0 for telnet connections, 1 for RS-232 and USB host
control).
0 = Clear/none;
1 = Verbose mode
2 = Tagged responses for queries
3 = Verbose mode and tagged responses for queries.
NOTE: If tagged responses is enabled, all read commands will return the constant string +
the data, like setting the value does.
For example command: E CN } response: Ipn • X10^]
X12! = Password (12 characters = maximum length; no special characters are allowed.)
NOTE: A user password cannot be assigned if no administrator password exists; the E14
error code is returned. If the administrator password is cleared, the user password is
also removed.
DVS 605 • SIS Communication and Control 40
