Press the SURROUND BACK button.
Lights when the Surround Back channel is on.
54
Basic Operation
Dolby Digital mode and DTS Surround
(only with digital input)
1
Press the STANDARD button to select
“STANDARD (Dolby/DTS Surround)” mode.
2
Play a program source with the ,
mark.
• The Dolby Digital indicator lights
when playing Dolby Digital
sources.
• The DTS indicator lights when
playing DTS sources.
lights
lights
3
Press the SURROUND PARAMETER button.
• The surround parameter menu appears.
5
Press the CURSOR
FF
or
GG
button to select the
setting.
6
Press the ENTER or SURROUND PARAMETER
button to complete the setting.
4
Press the CURSOR
DD
or
HH
button to select the
parameter.
SURROUND PARAMETER
STANDARD
ENTER
CURSOR
SURROUND BACK
CURSOR
NIGHT
SURROUND
PARAMETER
ENTER
STANDARD
lights
Set to “1spkr” Set to “2spkrs”
lights
LFE (Low Frequency Effect):
This sets the level of the LFE (Low Frequency Effect)
sounds included in the source when playing program
sources recorded in Dolby Digital, DTS, DVD-Audio or
Super Audio CD.
Program source and adjustment range:
1. Dolby Digital: –10 dB to 0 dB
2. DTS Surround: –10 dB to 0 dB
When DTS encoded movie
software is played, it is
recommended that the LFE LEVEL be set to 0 dB for
correct DTS playback.
When DTS encoded music
software is played, it is
recommended that the LFE LEVEL be set to –10 dB for
correct DTS playback.
TONE:
This adjusts the tone control ( page 63, 64).
This can be set individually for the separate surround mode other
than PURE DIRECT, DIRECT and Home THX Cinema mode.
• Select “Default Yes” and press the CURSOR
FF
button to
reset all the settings.
2 Surround parameters e
CINEMA EQ. (Cinema Equalizer):
The Cinema EQ function gently decreases the level of the
extreme high frequencies, compensating for overly-bright
sounding motion picture soundtracks. Select this function if
the sound from the front speakers is too bright.
This function only works in the Dolby Pro Logic
IIx, Dolby
Pro Logic, Dolby Digital, DTS Surround, DTS NEO:6 and
WIDE SCREEN modes.
D.COMP. (Dynamic Range Compression):
Motion picture soundtracks have tremendous dynamic
range (the contrast between very soft and very loud
sounds). For listening late at night, or whenever the
maximum sound level is lower than usual, the Dynamic
Range Compression allows you to hear all of the sounds in
the soundtrack (but with reduced dynamic range). (This
only works when playing program sources recorded in
Dolby Digital or DTS.) Select one of the four parameters
(“OFF”, “LOW”, “MID” (middle) or “HI” (high)). Set to
OFF for normal listening.
This parameter is displayed only when playing compatible
sources in DTS mode.
