70 Chapter 1
Agilent EXA Signal Analyzer
General
a. The LCD display is manufactured using high precision technology. However, there may be up
to six bright points (white, blue, red or green in color) that constantly appear on the LCD
screen. These points are normal in the manufacturing process and do not affect the measure-
ment integrity of the product in any way.
Description Specifications Supplemental Information
Data Storage
Standard
Internal Total Integrated 40 GB HDD 15 GB available on primary partition for
applications and secondary data
Internal User 6 GB available on separate partition for user
data
With Option PC2
Internal Total Removable 160 GB HDD 126 GB available on primary partition for
applications and secondary data
Internal User 9 GB available on separate partition for user
data
With Options SSD Requires Option PC2
Internal Total Removable 32 GB solid
state drive
14 GB available on primary partition for
applications and secondary data
Internal User 2 GB available on separate partition for user
data
Description Specifications Supplemental Information
Weight
(without options)
Net 16 kg (35 lbs) (nominal)
Shipping 28 kg (62 lbs) (nominal)
Cabinet Dimensions Cabinet dimensions exclude front and rear
protrusions.
Height 177 mm (7.0 in)
Width 426 mm (16.8 in)
Length 368 mm (14.5 in)
