MGP D5 Dicom Theater Lite 17
About the system
MGP D5 Dicom Theater provides consistent image quality for
consulting, reviewing and training applications. The system offers
a turnkey solution, bundling high-bright medical grade projector,
flat panel display, dedicated display controller and MediCal
QA management software. MGP D5 Dicom Theater is available in
single- head and dual - head configurations.
MGP D5 Dicom Theater facilitates consulting and reviewing: this
ceiling-mount medical projection system combines ClearBase
and Projector Native White modes, has a user-friendly remote
control and features versatile connectivity to add a multitude of
both color and grayscale application sources, including PACS, X-
ray, ultrasound, endoscopy, etcetera.
The MGP D5 Dicom Theater system includes TheaterWatch
software, which enables you to calibrate the projector(s) based
on a visual algorithm.
About the separate components
The BarcoMed 2MP2CP display controller generates the images
for the display and the projector. It is a dual-head board with two
video outputs, which allows it to send video signals to two
different display devices. Both video outputs can be defined to
deliver the same video signal or two separate video signals.
Both heads have separate Lookup Tables (LUTs), so that the
display curve or Preset can be defined and stabilized separately
for both display devices.
The MGP D5 projector has multiple inputs, allowing it to be used
for projecting the medical images on a large screen or displaying
other images, like text, spreadsheets, presentations, etcetera.
The LCD display is used as review display in the MGP D5 Dicom
Theater system. Calibration and stabilization of the display is
