3. Source Connections
Image 3-7
3.5 Connecting a RGB Analog s ource with Tri level c omposite sync
Which signal can be connected to the input?
RGB analog input terminals with tri level sync input or with tri level sync on green (BNC term inals). The projector detects automati-
cally where the sync signal is located.
Image 3-8
RGB3S or RG3sB connection
RGB3S or RG3sB selection via the RCU
1. Press digit button 4.
RGB3S or RG3sB selection via the local keypad
1. Press ADJUST key to start up the adjustment mode.
The General Access menu will be display ed. (image 3-9)
2. Use the cursor keys to highlight 4
3. Press ENTER to select the highlighted s ource.
