11. Messages, Warnings and Failures
11. MES SAGES, WARNINGS AND FA ILURES
Overview
• Messages
• Warnings
•Failures
11.1 Messages
Messages
INPUT 01 RGB2 Fh=064kHz Fv=060Hz When selecting a new source, following information ab out this sou rce
will be displayed on the sc reen: S ource number, horizontal and
vertical frequencies of the displayed source.
SOURCE 01 RGB2 Announcement of the selected source.
enter password XXXX Message to enter your password, password contains 4 digits.
WRONG PASSWORD !!! Message when the entered password is wrong
TEXT on SOURCE 01 RGB2 x xxkHz x xHz These messages w ill be displayed o n the screen when pushing the
TEXT key.
TEXT O n TEXT On: the ’bar scale indication’ will be enabled during the change
of an analog control in the ’operational mode’ + all warnings and
failures will be displayed.
TEXT O ff Text OF: the ’bar scale indication’ will be disabled during the change
of an analog control in the ’operational mode’ + all warnings and
failures will not be displayed.
PROJECTOR ADDRESS: 003 Indication of the projector add ress when activating the ’A DDRESS’
button on the RCU with a pencil or other small object.
11.2 Warni
ngs
War
nings
WARNING: Input not available When using the projector with the RCVDS, this warning will be display ed when
selecting an input slot of an RCVDS where the input board is missing.
WARNING: Source not av ailable The input is a valid input but the s ource is not conn ected t o the input terminals or
the input source is switched off.
WARNING: Invalid key intro When a wrong key is pressed on the RCU.
WARNING: End of adjust range End of adjustment range.
WARNING: Input no longer available The input source is no longer available.
WARNING: RCVDS not available The input source selector is not available.
WARNING: invalid frequency input The entered frequency or applied frequency of the source is out of the projector ’s
range.
WARNING: Option not installed ! Option no t ins talled. e.g. Video selected but no decoder installed.
R5976584 BARCO CINE7 26022003 101
