set port type wired-auth 87
Examples — The following command sets port 2 for a wired
authentication user:
WX1200# set port type wired-auth 2
success: change accepted
The following command sets port 7 for a wired authentication user and
subdivides the port into three virtual ports to support three simultaneous
user sessions:
WX1200# set port type wired-auth 7 1,2,3
success: change accepted
See Also
■ “clear port type” on page 61
■ “set port type ap” on page 82
Table 18 Wired Authentication Port Details
Port Parameter Setting
VLAN membership Removed from all VLANs. You cannot assign an MAP access
port to a VLAN. MSS automatically assigns MAP access ports
to VLANs based on user traffic.
Spanning Tree
Protocol (STP)
Not applicable
802.1X Uses authentication parameters configured for users.
Port groups Not applicable
IGMP snooping Enabled as users are authenticated and join VLANs.
Maximum user
sessions
1 (one).
