set port type ap 85
This command does not apply to any gigabit Ethernet ports or to ports 7
and 8 on the WX1200 switch. To manage a MAP access point on a
WX4400switch, use the set dap command to configure a Distributed
MAP connection on the switch.
Examples — The following command sets ports 1 through 3 and port 5
for MAP access point model AP2750 and enables PoE on the ports:
WX1200# set port type ap 1-3,5 model ap2750 poe enable
This may affect the power applied on the configured ports.
Would you like to continue? (y/n) [n]y
The following command sets ports 4 through 6 for MAP access point
model AP2750, enables PoE on the ports, and sets the radio type to
802.11a:
WX1200# set port type ap 4-6 model ap2750 poe enable
radiotype 11a
This may affect the power applied on the configured ports.
Would you like to continue? (y/n) [n]y
The following command resets port 5 by clearing it:
WX1200# clear port type 5
This may disrupt currently authenticated users.
Are you sure? (y/n) [n]y
success: change accepted.
Table 17 MAP Access Port Defaults
Port Parameter Setting
VLAN membership Removed from all VLANs. You cannot assign an MAP
access port to a VLAN. MSS automatically assigns MAP
access ports to VLANs based on user traffic.
Spanning Tree Protocol
(STP)
Not applicable
802.1X Uses authentication parameters configured for users.
Port groups Not applicable
IGMP snooping Enabled as users are authenticated and join VLANs.
Maximum user
sessions
Not applicable
