Operations Manual, HPA2, Compact Outdoor SSPA 205486 REV F 105
11.1.1 System Information sub-menu
The informative sublevel of the menu structure contains five (5) pages, as shown in Figure
11-2.
11.1.1.1 Sys Info Page 1
The page shows:
• The SSPA current level of attenuation, measured in dB (Atten.(dB):XX.X) with
accuracy of 0.1 dB;
• Alarm presence, “FAULT!” or “None” will be displayed depending on the state of the
SSPA;
• Forward RF Power in dBm with accuracy of 0.1 dBm;
• Current base plate temperature, measured in Centigrade.
11.1.1.2 Sys Info Page 2
The page shows a variety of alarm states which may be present within the SSPA. Fault
values are “Fault” or “Normal”.
• Voltage – RF Module voltage regulator low voltage fault;
• Current – Low DC current fault;
• Temperature – high temperature fault;
• Spare – spare fault can reflect various fault conditions and events.
Atten.(dB):XX.X
Alarms:XXXXXX
RFOut(dBm):XX.X
Temp.(C):XXX
Active Keys:(U)p+Enter; (D)own+Enter; (C)lrearFlt; (M)enu+Enter; (E)nd+Enter
Voltage:XXXXXX
Current:XXXXXX
Temperature:XXXXXX
Spare:XXXXXX
Active Keys:(U)p+Enter; (D)own+Enter; (C)lrearFlt; (M)enu+Enter; (E)nd+Enter
BUC:XXXXXX
AUX:XXXXXX
Int.Mute:XXXXXX
Ext.Mute:XXXXXX
State:XXXXXX
Ctrl:XXXXXX
Active Keys:(U)p+Enter; (D)own+Enter; (C)lrearFlt; (M)enu+Enter; (E)nd+Enter
DCCur.(A):XX.X
Regul.(A):XX.X
Gate(V):XX.X
PS(V):XX.X
RFSW:XXXXXX
Active Keys:(U)p+Enter; (D)own+Enter; (C)lrearFlt; (M)enu+Enter; (E)nd+Enter
Prtcl:XXXXXXXX
Baud:XXXXX
Addrs:XXX
Unit:XXXX
Mode:XXXXXXX
Active Keys:(U)p+Enter; (D)own+Enter; (C)lrearFlt; (M)enu+Enter; (E)nd+Enter
Figure 11-2: System Information menu structure
