IMPORTANT:
To operate JVC’s audio components using this remote control:
• You need to connect JVC audio components through the COMPU
LINK-3 (SYNCHRO) jacks (see page 47) in addition to the
connections using cables with RCA pin plugs (see pages 6 and 7).
• If you use the buttons on the front panel or the menu function to
choose a source, the remote control will not operate that source.
To operate a source with the remote control, the source must be
selected using source selecting buttons on the remote control.
• To operate the cassette deck or MD recorder using the COMPU
LINK remote control system, set the source name correctly. (See
page 23.)
• Refer also to the manuals supplied with your components.
Operating JVC’s Audio/Video Components
You can operate JVC’s audio and video components with this receiver’s remote control, since control signals for JVC
components are preset in the remote control.
Check to see if the
multi-room
operation selector
is set to the
correct position.
To operate the
receiver for the
main room, set it
to “MAIN ROOM.”
To operate the
receiver for the
sub-room, set it
to “SUB ROOM.”
Tuner
You can always perform the following operations (with the remote
control mode selector set to “AUDIO/TV/VCR”):
FM/AM: Alternates between FM and AM.
After pressing FM/AM (with the remote control mode selector set to
“AUDIO/TV/VCR”), you can perform the following operations:
1 – 10, +10: Selects a preset channel number directly.
For channel number 5, press 5.
For channel number 15, press +10, then 5.
For channel number 20, press +10, then 10.
TUNING UP/TUNING DOWN:
Tunes into stations.
FM MODE: Changes the FM reception mode.
Sound control section (Amplifier)
You can always perform the following operations (with the remote
control mode selector set to “AUDIO/TV/VCR”):
SURROUND ON/OFF: Turns on or off the Surround modes —
Dolby Pro Logic, Dolby Digital, and DTS
Digital Surround.
SURROUND MODE: Selects the DSP modes.
After pressing SOUND (with the remote control mode selector set
to “AUDIO/TV/VCR”), you can perform the following operations:
SEA MODE: Changes the SEA modes.
SUBWOOFER – / +: Adjusts the subwoofer output level.
CENTER – / +: Adjusts the center speaker output level.
REAR•L – / +: Adjusts the left rear speaker output level.
REAR•R – / +: Adjusts the right rear speaker output level.
CNTR TONE: Selects the center tone.
REAR TONE: Selects the rear tone.
TEST: Turns on or off the test tone output.
Note:
After adjusting sounds, press the corresponding source selecting
button or CD-DISC to operate your target source by using the 10
keys; otherwise, the 10 keys cannot be used for operating your target
source.
CD player
After pressing CD (with the remote control mode selector set to
“AUDIO/TV/VCR”), you can perform the following operations on
the CD player:
PLAY: Starts playing.
44
44
4: Returns to the beginning of the current (or
previous) track.
¢¢
¢¢
¢: Skips to the beginning of the next track.
STOP: Stops playing.
PAUSE: Pauses playing. To release it, press PLAY.
1 – 10, +10: Selects a track number directly.
For track number 5, press 5.
For track number 15, press +10, then 5.
For track number 20, press +10, then 10.
For track number 30, press +10, +10, then 10.
RM-SRX9000J REMOTE CONTROL
CONTROL
CHANNEL VOLUMETV VOL
TUNING
STOP PAUSE
FF/
/REW
VCR 1
TV/VIDEO
TAPE/MD
MUTING
REC
PLAY
DOWN UP
DVD DVD MUILTI CD TAPE/MD
TV/DBS VIDEO PHONO FM/AM
VCR 1
CDR/VCR 2
ANALOG/DIGITAL
SURROUND CNTR TONE
CENTER
SURROUND
REAR TONE
REAR-L
CD-DISC
MODE
ON/OFF
SEA MODE REAR-R
SOUND
TEST
SUBWOOFER
RETURN FM MODE
SET
MENU
AUDIO/
TV/VCR
EXIT
TEXT
DISPLAY
SLEEP
123
456
7
/P
89
10
0
+10
100+
CATV/DBS
MENUMENU
ENTERENTER
STANDBY
ON
TV/CATV/DBS
VCR 1
POWER POWER
MAIN ROOM
SUB ROOM
SUB
ROOM
MAIN
ROOM
ON/OFF ON/OFF
AUDIO/
TV/VCR
CATV/DBS
SUB
ROOM
MAIN
ROOM
Check to see if the
remote control mode
selector is set to the
correct position.
To operate the
audio system, TVs,
VCRs, and DVD
players, set it to
“AUDIO/TV/VCR.”
