Image 8-45
Input white balance Red
50
0
127
Image 8-46
If one uses a gray scale pattern, the bright spots should appear in the white bar.
Selecting Preset restores the factory input balance setting
8.10.3 Input balance for YPrPb signals
Remark on the input balance of a component video source
Before starting the Input Balance procedure, generate a signal with dominant white parts.
Input balance is also available for a component video source under following conditions:
• A component video signal is present on the BNC’s.
• ”Data on BNC’s” is selected in the Source selection menu.
• Pr/Y/Pb is selected in the Advanced menu of the corresponding image file.
The procedure is the same as for a data source except:
