68
INSTALLATION SETTINGS
All ON/Fixed Volume
Step 6. Master Key #1 lights up, indicating you are
ready to adjust ALL ON Volume if the zone is set to
variable mode. If the zone is set to fixed mode, you
are adjusting the volume level to which the zone will
always be set.
Step 7. Use the Volume Up / Down keys to adjust
the zone ALL ON/Fixed Volume.
Important Note: When setting Fixed Volume for
zones using Silencers, be sure to turn the volume
knob of the Silencer to the full volume position
(turned fully clockwise). Then set the volume to
the a level appropriate for full the volume setting
in that zone.
Bass
Step 8. Tap Master Key #2. Master Key #2 lights
up, indicating it is ready to adjust Bass.
Step 9. Use the Volume Up key to increase bass
and the Volume Down key to decrease it.
Treble
Step 10. Tap Master Key #3. Master Key #3 lights
up, indicating it is ready to adjust treble.
Step 11. Use the Volume Up key to increase treble
and the Volume Down key to decrease it.
Balance
Step 12. Tap Master Key #4. Master Key #4 lights
up indicating it is ready to adjust balance.
Step 13. Use the Volume Up key for the right
speaker and the Volume Down key for the left.
Loudness
Zones are set to loudness OFF as the default.
Step 14. When using Solo
™
keypads, tap the Arrow
Up key to turn loudness ON.
Important Note: When using a Solo
™
keypad mod-
ule, you must press any one of the Master Keys prior
to setting Loudness. The Arrow Up key won't work
unless one of the Master Keys is illuminated.
or
When using Select
™
keypads, tap Master Key 5 to
turn loudness ON.
Step 15. Tap the same key again (depending on
your keypad module) to turn loudness OFF.
Flat
Tap any other key (besides the five Master Keys and the
Arrow Up key) for acoustic adjustments to revert to flat.
You may tap any other key including those from
Transport
™
or Numeric
™
Modules installed in the room.
Step 16. Press the OFF Key on the Master Keypad
connected to that zone to memorize the new settings.
Follow steps 2– 16 for all zones requiring acoustic
adjustment.
To exit Acoustic Adjustment Mode
Step 1. Press the OFF button to turn the zone OFF.
The LED for the last zone ON blinks GREEN.
Step 2. Press the Program button to exit Acoustic
Adjustment Mode.
