Solo™ Master
Keypad Module
11
PARTS GUIDE SOLD SEPARATELY
Master Keys
Function Keys
Zone OFF Key
Mute Key
Zone Volume Key
Master Keys
Zone OFF Key
Mute Key
Zone Volume Key
Function Keys
Transport™ Master
Keypad Module
Numeric™ Master
Keypad Module
Select™ Master
Keypad Module
IntelliPad Ci Keypad Modules
Figure 5
Master Keys
A quick tap of any of these keys turns on the zone and selects a source component. Pressing and holding
these buttons for longer than three seconds turns on all enabled zones. Also, all zones are selected to the
same source component.
Zone OFF Key
A quick tap of this Key turns your specific ZONE OFF. Pressing and holding this button for longer than three
seconds causes ALL ZONES to turn OFF.
Volume Keys
A continuous press of these buttons raises or lowers the volume in your specific ZONE. Pressing these but-
tons also restores sound in a muted zone.
Zone Mute Key
A quick tap of this button mutes the sound in a ZONE. A quick tap of this button restores sound in a muted zone.
Function Keys
Pressing these keys issues the individual IR commands programmed for control of the connected source
components.
