Adjusting Settings
Speaker settings
<SPEAKER>
FH CROSS
(Front high speakers crossover frequency)
CROSS 40 Hz to CROSS 200 Hz (10 Hz
step)
SP IMP.
(Speaker Impedance)
8 ohm, 4 ohm
Input settings
<INPUT>
NAME IN (Naming inputs) For reference on this function, see“Input
Edit” in Input Settings menu (page 103).
INPUT SKIP (Input skip) SHOWN, HIDDEN
H.A. ASSIGN (HDMI audio assign) For reference on this function, see“Using
other video/audio input jacks” (page 82).
H.V. ASSIGN (HDMI video assign) For reference on this function, see “Using
other video/audio input jacks” (page 82).
A. ASSIGN (Digital audio assign) For reference on this function, see “Using
other video/audio input jacks” (page 82).
V.ASSIGN (Component video assign) For reference on this function, see “Using
other video/audio input jacks” (page 82).
Surround settings
<SURROUND>
S.F. MODE (Sound field mode) FRONT HIGH, STANDARD
HD-DCS TYP
(HD-D.C.S. effect type)
DYNAMIC, THEATER, STUDIO
H. GAIN
(PLIIz Height Gain Control)
HIGH, MID, LOW
EQ settings
<EQ>
FRT BASS
(Front speakers bass level)
FRT B. –10 dB to FRT B. +10 dB
(0.5 dB step)
FRT TREBLE
(Front speakers treble level)
FRT T. –10 dB to FRT T. +10 dB
(0.5 dB step)
CNT BASS
(Center speaker bass level)
CNT B. –10 dB to CNT B. +10 dB
(0.5 dB step)
CNT TREBLE
(Center speaker treble level)
CNT T. –10 dB to CNT T. +10 dB
(0.5 dB step)
SUR BASS
(Surround speakers bass level)
SUR B. –10 dB to SUR B. +10 dB
(0.5 dB step)
SUR TREBLE
(Surround speakers treble level)
SUR T. –10 dB to SUR T. +10 dB
(0.5 dB step)
FH BASS
(Front high speakers bass level)
FH B. –10 dB to FH B. +10 dB
(0.5 dB step)
FH TREBLE
(Front high speakers treble level)
FH T. –10 dB to FH T. +10 dB
(0.5 dB step)
Multi-zone
settings
<ZONE>
P.VOL MAIN
(Preset Volume (MAIN))
OFF, –∞,–92.0 dB to +23.0 dB (0.5 dB
step)
P.VOL ZONE2
(Preset Volume (Zone2))
OFF, –∞,–92 dB to +18 dB (1 dB step)
Z2 LINEOUT
(Zone2 Line Out Level Type)
FIXED, VARIABLE
12V TRIG.
(12V Trigger)
OFF, CTRL, ZONE, INPUT
Menu Item Parameter
continued
