Setup JBL Performance
3-30
CUSTOM SPEAKER SETUPS (continued)
SUBWOOFER FULL, 30HZ to 120Hz, THX 80Hz, NONE
Opens the SUBWOOFER menu, which is use to select a crossover
point for the audio output connector labeled Subwoofer. When set
to FULL, the AV1 sends a full-range audio output signal to this con-
nector. Otherwise, the AV1 activates a crossover point at the
selected setting. Choose the setting equal to the lowest setting of
the other speakers.
Note:
When the SUBWOOFER parameter is set to NONE, subwoofer signals will
not be redirected if the 5.1a BYPASS listening mode is activated. Use the
associated DVD-A/SACD player to configure the speaker setup to redirect
subwoofer signals .
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGER
LOCK OPTIONS
SPEAKER SETUP
CUSTOM SETUP
THX SETUP
SPEAKER DISTANCES
LEVELS CALIBRATION
C
R SR RR
L SL RL
M
SUB
40Hz
60Hz
60Hz
60Hz
40Hz
40Hz
60Hz
60Hz
SUBWOOFER
FULL
30 Hz
40 Hz
50 Hz
60 Hz
70 Hz
80 Hz
80 Hz
90 Hz
100 Hz
110 Hz
120 Hz
CUSTOM SETUP
FRONT L/R
CENTER
SIDE L/R
REAR L/R
SUBWOOFER
ULTRA2 SUB
BGC
ASA
40 Hz
60 Hz
60 Hz
60 Hz
40 Hz
OFF
N/A
APART
SPEAKERSSETUP
CUSTOM SETUP
SUBWOOFER
