AV1 Setup
3-19
INPUT SELECT PARAMETER SETTINGS
The table below describes INPUT SELECT parameter settings.
DIGITAL ANALOG AUTO
The AV1 automatically sets the INPUT SELECT
parameter to DIGITAL when the ANALOG IN
parameter is set to NONE.
• The AV1 sends the assigned digital audio
input connector to the audio output
connectors. The AV1 ignores the
assigned analog audio input connector.
• The digital audio input connectors are com-
patible with PCM (44.1kHz, 48kHz,
88.2kHz and 96kHz), Dolby Digital and
DTS(-ES) sources. If an incompatible digital
audio source (for example, MPEG or MP3)
is present, the AV1 automatically selects the
assigned analog audio input connector.
• The DIGITAL IN parameter assigns a dig-
ital audio input connector for the
selected input.
The AV1 automatically sets the INPUT SELECT
parameter to ANALOG when the DIGITAL IN
parameter is set to NONE.
• The AV1 sends the assigned analog audio
input connector to the audio output con-
nectors. The AV1 ignores the assigned digi-
tal audio input connector.
• The ANALOG IN parameter assigns an ana-
log audio input connector for the selected
input.
The AV1 automatically sets the INPUT SELECT
parameter to AUTO when both digital and
analog audio input connectors are assigned.
• The AV1 toggles between sending the
assigned digital and analog audio input
connectors to the audio output connec-
tors based on the input source that is
present. For example:
- When a 2-channel PCM, Dolby Digital
or DTS(-ES) source is present, the AV1
automatically selects the assigned digi-
tal audio input connector.
- When an SACD source is present and a
digital source is not present, the AV1
automatically selects the assigned ana-
log audio input connector.
• The AUTO setting is recommended for
components that generate both digital
and analog signals, such as DVD/SACD
players.
