AV1 Appendix
A-3
Specifications subject to change without notice.
Component Video Performance
Compatibility 3-channel (Y, Pr, Pb), format-independent
Switching Passive
Impedence 75Ω
Insertion Loss <3dB
Bandwidth >150MHz
Other
Trigger Outputs 1 power on/off and 1 programmable connector on detach-
able screw terminals (+12 VDC, 0.5 amps each)
RS-232 Serial Input/
Output
2 9-pin D-sub connectors
Power Requirements 90-250 VAC, 50-60Hz, 60W (universal line input), detach-
able power cord
AV1 Dimensions &
Weight
• Height (with feet): 3.81 inches (97mm)
• Width: 17.3 inches (440mm)
• Depth: 14.85 inches (377mm)
• Weight: 17lbs (7.6kg)
Rack Mounting Optional brackets are available for installation in a standard
19" equipment rack (2 rack units required for AV1).
Environment • Operating Temperature: 0° to 35°C (32° to 95°F)
• Storage Temperature: -30° to 75°C (-22° to 167°F)
• Relative Humidity: 95% maximum without condensation
Remote Control • Hand-held, backlit infrared remote control unit
• Requires 2 AA batteries (Alkaline batteries recommended)
