Setup JBL Performance
3-26
CUSTOM SPEAKER SETUPS (continued)
FRONT L/R FULL, 30Hz TO 120Hz, THX 80Hz
Opens the FRONT L/R SPEAKERS menu, which is used to select a
crossover point for the audio output connectors labeled Front L/R.
When set to FULL, the AV1 sends a full-range audio output signal to
these connectors. Otherwise, the AV1 activates a crossover point at
the selected setting. Choose the setting closest to the low-fre-
quency rating of associated speakers.
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGER
LOCK OPTIONS
SPEAKER SETUP
CUSTOM SETUP
THX SETUP
SPEAKER DISTANCES
LEVELS CALIBRATION
C
R SR RR
L SL RL
M
SUB
40Hz
60Hz
60Hz
60Hz
40Hz
40Hz
60Hz
60Hz
FRONT L/R SPEAKERS
FULL
30 Hz
40 Hz
50 Hz
60 Hz
70 Hz
80 Hz
80 Hz
90 Hz
100 Hz
110 Hz
120 Hz
CUSTOM SETUP
FRONT L/R
CENTER
SIDE L/R
REAR L/R
SUBWOOFER
ULTRA2 SUB
BGC
ASA
40 Hz
60 Hz
60 Hz
60 Hz
40 Hz
OFF
N/A
APART
Parameter
Default
Setting
Possible
Setting
FRONT L/R 40Hz FULL, 30Hz to 120Hz, THX 80Hz
CENTER 60Hz FULL, 30Hz to 120Hz, THX 80Hz,
NONE
SIDE L/R 60Hz FULL, 30Hz to 120Hz, THX 80Hz,
NONE
REAR L/R 60Hz FULL, 30Hz to 120Hz, THX 80Hz,
NONE
SUBWOOFER 40Hz FULL, 30Hz to 120Hz, THX 80Hz,
NONE
THX ULTRA2 SUB OFF ON, OFF
BGC N/A ON, OFF
ASA APART TOGETHER, CLOSE, APART
SPEAKERSSETUP
CUSTOM SETUP
FRONT L/R
