Picture Control in Adjustment Mode
9-3
5975338 BARCOVISION 9200 210497
Screen operations
Select the
Picture Control
menu on the Main menu by pushing the
control disk up or down. Press ENTER to select.
Push the control disk up or down to select
Screen operations
. Press
ENTER to select.
When pushing continuously on the control disk, the adjustment will
be executed in an accelerated fashion.
MAIN MENU
832a
Picture Control
System Settings
File service
Service Mode
PICTURE CONTROL
860b
Signal operation
Screen operation
SCREEN OPERATIONS
Zoom/Pan
Geometry (off)
Configure
867
Zoom/pan
Push the control disk up or down to highlight
Zoom/Pan
and press
ENTER to select.
All functions, e.g. move, enlarge, reduce, stretch, can be done on a
"Window"
or on a
"Picture"
.
SCREEN OPERATIONS
868a
Zoom/Pan
Geometry (off)
Configure
870
Screen
Window
Window
A window determines the maximum area used on the screen to
project a picture.
This window can be placed in any position on the screen using the
move, reduce and stretch controls. During a first start up, the window
will be on its maximum dimensions. Enlarging and moving is not
possible in this maximum position.
Create now using the following controls a desired window on the
screen. With these functions, all aspect ratios are possible.
Select the controls by pushing the control disk to the right or to the left
and press
ENTER to activate the control.
870870
[window]
moves the window to the left.
870
870
[window]
moves the window to the right.
