66
Additional Information
Setup Menu Table
The following table provides an overview of the various Setup Menu items, including their parameters, factory setting, and
reference page (s) in the manual.
To access the Setup Menu
Press MENU/NO twice ; “Setup Menu” appears in the display.
(Note : The menu items available when MENU/NO is pressed may vary according to the current status of the recorder.)
Menu item Function Parameters Factory Page(s)
setting
Program? Creates a program — — 33
M. Access? Creates a program — — 34
Play Mode Selects Play Mode Continue Continue 27
Shuffle 32
Program 33
M. Access 34
Repeat Mode Selects repeat mode Repeat Off Off 31
Repeat All 31
Repeat 1 31
A-B Repeat 32
A. Cue Level Sets the level for detecting the start of track _72 to _48dB _72dB 38
A Cue Offset Adjusts the position of the start of auto-cue ±1 sec. 0 38
Music Scan Adjusts playback time of music scan 6 to 20 sec. 6 sec. 29
Mark Rehear Adjusts position of mark — — 37
Direct Mark Mark poistion time is directly input — — 36
Output Level Adjusts analog signal output level _20.2 to 0 dB 0dB 28
Input Level Coax Adjusts the level of the digital input _ ∞ to +18dB 0dB 21
signal from the COAXIAL terminal
Input Level OPT Adjusts the level of the input from _ ∞ to +18dB 0dB 21
the OPTICAL terminal
Input Level Anlg Adjust the level of the input from _ ∞ to +12dB 0dB 21
the ANALOG terminal
Anlg In L/R Adjust difference between left and right — 0dB 21
output of ANALOG signal
Rec Mode Selects recording mode Stereo Stereo 20
Mono 20
Long 2 20
Long 4 20
Smart Space Sets Smart Space and AutoCut On/Off On 22
Track Mark Sets track marking method Level Sync Level/Sync 23
Off 23
Interval 23
Tr Mark Level Sets base level for auto track marking _72 to _48dB _72dB 23
Interval Sets constant time interval of auto-track 1 to 10 min. 1 min. 23
marking
Peak Hold Indicates the highest level of the signal On/Off Off 21
End Of Tr/Disc Indicates time to end of track in playback, On/Off Off 53
end of disc in recording
EOT (Play) Sets time of indication of end of 6 to 20 sec. 6 sec. 53
track in playback
EOD (REC) Sets time of indication of end of 3 to 10 min. 3 min. 53
disc in recording
Resume Mode Turns off resume mode. Resume Off Resume Off 36
Play starts position of previous stop. Resume Play 36
Play starts next track of previous stop. Resume Next 36
Timer Turns off timer function. Off Off 54
Starts playback when power is turned on. Play 54
Starts recording when power is turned on. Rec 54
