Digital output 2
subwoofers
The RCS 2.2XP has three digital outputs for subwoofer(s) :
•
1
S/PDIF (RCA)
•
1 AES/EBU (XLR)
•
1
Optical (T
osLink)
Optical (TosLink)Optical (T
All outputs are 24-bits at 44.1, 48, 88, 96 or 192 kHz sampling rates. The output
sampling rate is set in the
“
DOUT
”
menu. (TosLink does not support 192kHz)
The sub output is for your subwoofer(s) and can be confi gured for either mono or
stereo. Use the
“
MODE
”
menu to set the appropriate output mode 2.0, 2.1, or 2.2.
Connect one of these outputs to a TacT digital amplifi er or external DA converter.
Optional modules
The RCS 2.2 XP is designed to accommodate virtually any input and output needed
without adding extra cost for features certain users might not use. There are there-
fore 3 optional modules that can be installed:
•
ADC-converter module for analog inputs such as Tuners,
Cassette decks, VCRs etc.
•
DAC-converter module for main channels, needed when the
RCS 2.2 XP is used with traditional analog amplifi ers
•
DAC-converter module for subwoofer(s), needed when the
RCS 2.2 XP is used with analog self-powered subwoofer(s)
These modules are based on the latest 24-bits/192 kHz state-of-the-art technology
and offer performance far beyond that of most stand-alone converters. Due to the
modular design of the RCS 2.2 XP, these modules can be added at any time or
exchanged if upgrades should become available.
RCS 2.2 XP Connections
