50-EN
Adjusting the DVD Level
The volume (signal level) for Dolby Digital, Dolby PL II, DTS and
PCM modes can be set.
•Avoid stopping, pausing, switching the disc, cueing, fast-
forwarding or switching the audio channel of this unit while
making this adjustment. The setting is canceled if the Decode mode
is switched.
1
Check that Defeat mode is off.
2
Press SOURCE/POWER.
The main menu is displayed.
3
Press 4 (A.PROC).
The A.PROC (Audio processor) list display appears.
4
Turn the Rotary encoder to select “DVD LEVEL.”
5
Press 1 (SETUP).
The DVD LEVEL list display appears.
6
Turn the Rotary encoder to select a mode to be
adjusted.
7
Press 1 (LEVEL ;DN) or 2 (LEVEL UP :) to
adjust the level.
The level can be adjusted in the range of –5 to +5.
Storing Settings in the Memory
Adjustment or setting contents can be stored.
Contents that can be stored vary depends on the audio processor used.
1
Check that Defeat mode is off.
2
Press SOURCE/POWER.
The main menu is displayed.
3
Press 4 (A.PROC).
The A.PROC (Audio processor) list display appears.
4
Turn the Rotary encoder to select “PRESET
MEMORY.”
The Function Guide changes.
5
Press one of 1 (P.SET1) to 6 (P.SET6) for more
than 2 seconds.
The setting contents are stored.
• The stored contents will not be deleted even when the battery
power cord is detached.
Getting out the Preset Memory
1
Check that Defeat mode is off.
2
Press SOURCE/POWER.
The main menu is displayed.
3
Press 4 (A.PROC).
The A.PROC (Audio processor) list display appears.
4
Turn the Rotary encoder to select “PRESET
MEMORY.”
The Function Guide changes.
5
Press one of 1 (P.SET1) to 6 (P.SET6) to select
the preset memory you want to get out.
• It takes a few moment to get out the preset memory.
6
5
4
3
2
1
SOURCE/POWER
Rotary encoder
Adjusting the speaker levels
The test tones help to make the volume adjustments of the different
speakers. When levels are equal, a strong sense of presence can be
heard from the different speakers at the listening position.
•Avoid stopping, pausing, switching the disc, cueing, fast-
forwarding or switching the audio channel of this unit while
making this adjustment. The setting is canceled if the decode mode
is switched.
1Turn the Rotary encoder to select OUTPUT LEVEL.
2Press 1 (AUTO).
Test tone output is repeated for each of the different
speaker channels. They will be repeated in the order
shown below.
If no operation is performed for 2 seconds, the channel
switches to the next channel.
Left → Center → Right → Right Surround →
Left surround → Left
3 While the test tones are being produced from the
speakers, press 2 (LEVEL ; DN) or 3 (LEVEL UP
:) to adjust so that the volume of the different speakers
is equal.
• The adjustment range for the different speakers is
–10 dB - +10 dB.
• Adjust based on the front speakers.
• If a speaker is set to off mode, that speaker’s level adjustment
cannot be made.
Refer to “Speaker Setup” (page 48).
