23
Getting connected
The bundled AM loop antenna is designed
for indoor use only.
Using the bundled AM loop antenna
1. Assemble the AM antenna, as shown.
The AM antenna needs to be connected
to the AM terminals located on the rear
of the CR-N1, as shown.
2. To connect an antenna wire, push the
terminal lever, insert the bare wires, and
then release the lever, as shown.
Make sure that the wires are attached
securely and that the terminals are grip-
ping the bare wires, not the insulation.
Once the CR-N1 is ready for use, you’ll
need to tune into an AM radio station
and adjust the position of the AM
antenna in order to achieve the best pos-
sible reception. Keep it as far away as pos-
sible from the CR-N1, speaker cables,
power cord, and your computer.
Using an outdoor AM antenna
If good reception cannot be achieved using
the bundled AM loop antenna, an outdoor
AM antenna can be used as well, as shown.
Outdoor AM antennas work best outside,
but good results can sometimes be obtained
indoors by mounting horizontally above a
window. Note that the AM loop antenna
should be left connected.
Outdoor antenna must be grounded in
accordance with local regulations to prevent
electrical shock hazards. See item 14 of
“Important safeguards” at the front of this
manual.
Connecting an AM antenna
Insert into the hole.
1. Push
2. Insert
3. Release
Outdoor
antenna
