CHAPTER 3 - BIOS SETUP
SYS7180VE User’s Manual
37
Description Choice
Delay Transaction
The chipset has an embedded 32-
b
it posted write
b
uffer to support delay transactions cycles.
Select Enabled to support compliance with PCI
specification version 2.1.
Delay Prior to Thermal
Select the interval to setup the delay timer for
CPU Thermal-Throttling.
AGP Aperture Size (MB)
Select the size of the Accelerated Graphics Port
(AGP) aperture. The aperture is a portion of the
PCI memory address range dedicated for
graphics memory address space. Host cycles that
hit the aperture range are forwarded. Host cycles
that hit the aperture range are forwarded to the
AGP without any translation.
On-Chip VGA setting
On-Chip VGA
When Enabled to choice the on-
b
oard VGA
function, otherwise disabled the on-
b
oard VGA
function.
CHAPTER 3 - BIOS SETUP
38
SYS7180VE User’s Manual
Description Choice
On chip Frame buffer size
When Enabled, a fixed VGA frame buffer from
A000h to BFFFh and a CPU-to-PCI write buffer
are implemented.
3.6 Integrated Peripherals
Description Choice
