Advanced Settings
28
Setting item Default Value Setting Details
PLIIx Music
(2ch Input)
Dimension
0 Adjust the sound field setting for playing any
2 ch digital source such as Dolby Digital or 2
ch analog/PCM source in the Dolby PrologicII
Music listening mode. Select the depth of sound
field.
"-3" to "+3": The sound field shifts forward as
the set value becomes smaller than "0" and
backward if the set value become larger than
"0".
PLIIx Music
(2ch Input)
Center Width
3 Configure the setting to use for playing any 2
ch digital source such as Dolby Digital, or 2-ch
analog/PCM source in the Dolby PrologicII
Music listening mode. Adjust the width of the
sound from the center speaker).
"0" to "7": The smaller the setting value is, the
more concentrated in the center speaker is
the sound, while the larger the setting value is,
the more distributed to the front left and right
speakers is the sound of the center speaker.
PLIIz Height Gain Mid Adjust the output level of the height speakers
in the Dolby Pro Logic IIz Height listening
mode. The output of the height speakers will be
enhanced in the order of "Low", "Mid" (Middle),
"High":"Low", "Mid" and "High".
• In the following cases, the setting cannot be
changed:
– "Height" is set to "None" in "Speaker
Configuration".
– "Powered Zone 2" is set to "Yes" and also
Zone2 is set to on.
Dolby EX Manual The Dolby Digital EX listening mode will
automatically be selected when Dolby EX
signals are input.
"Auto": Use this function
"Manual": Select the desired listening mode
• In the following cases, the setting cannot be
changed:
– "Back" is set to "None" in "Speaker
Configuration".
– "Powered Zone 2" is set to "Yes" and also
Zone2 is set to on.
Setting item Default Value Setting Details
Loudness
Management
On Enable the Late Night function that allows
you to enjoy surround sound of Dolby TrueHD
playback even in low volume.
"On": Use this function
"Off": Do not use this function
• Depending on the setting of "Back" in "Speaker Configuration", the display will be changed. "PLllx" will
be displayed as "PLllx/PLII"
