Specifications
Amplifier/Tuner Section
Amplifier
Output Power
SPEAKERS A (IEC 268-3/DIN) (Main) 20 watts per channel, min. RMS, both channels driven, into 6 ohms at 1 kHz
with no more than 0.9% total harmonic distortion.
SPEAKERS B (Subwoofer) 30 watts per channel, min. RMS, both channels driven, into 3 ohms at 80 Hz,
with no more than 10% total harmonic distortion.
Input Sensitivity/Impedance (1 kHz)
TV SOUND/VCR 400 mV/47 kohms
Output Impedance (1 kHz)
TV SOUND/VCR 6.8 kohms
Preset S.E.A. 3 patterns
Manual S.E.A. Control ±6 dB at 150 Hz (2 dB step)
±6 dB at 1 kHz (2 dB step)
±6 dB at 10 kHz (2 dB step)
Speaker terminals
SPEAKERS A 6 - 16 ohms
SPEAKERS B 3 - 16 ohms
Tuner
FM Tuner
Tuning Range 87.5 - 108.0 MHz
AM Tuner
Tuning Range
MW 522 - 1,629 kHz
LW 144 - 288 kHz
Dimensions 196 × 145 × 352 mm (W/H/D)
(7-3/4 × 5-3/4 × 13-7/8 inches)
Mass 5.1 kg (11.3 lbs)
CD Player/Cassette Deck Section
CD Automatic Changer
CD Capacity 3 discs
Dynamic Range 96 dB
Signal-To-Noise Ratio 96 dB
Wow And Flutter Unmeasurable
Cassette Deck
Frequency Response
Type II (CrO
2
) : 30 - 16,000 Hz
Type I (NORMAL) : 30 - 15,000 Hz
Wow And Flutter 0.09% (WRMS)
Dimensions 196 × 145 × 348 mm (W/H/D)
(7-3/4 × 5-3/4 × 13-3/4 inches)
Mass 4.2 kg (9.3 lbs)
Accessories
AM (MW/LW) Loop Antenna (1)
Remote Control (1)
Batteries R6P (SUM-3)/AA (15F) (2)
FM Wire Antenna (1)
External Wire (1)
Power Specifications
Power Requirements AC 230 V , 50 Hz
Power Consumption 89 watts
12 watts (in standby mode)
Design and specifications are subject to change without notice.
