Using the CD Player
DISC button indicator
The buttons DISC 1, DISC 2, and DISC 3 act as indicators for the corresponding trays.
This indicator is off when the CD Player is checking that there is no disc in the disc tray for the selected
disc number.
Pressing the 0 button turns the indicator on.
Disc display
A disc marker lights on the disc display for the disc number you have selected. The CD indicator blinks
while a CD is being played.
The CD indicator, for the disc tray corresponding to the “NO DISC” display, goes out.
The CD indicator for the disc tray which is opened with the Main Tray lights up.
The CD indicator for disc that have been played are dimmed slightly compared to discs that have still to
be played, or are being played.
SEA
MENU
CANCEL
SET
ENTER
FM/AM
TV SOUND/VCR
VOLUME
H
3D-PHONIC
S. A. BASS
REC START
/STOP
CD REC
START
COUNTER
RESET
DOLBY B NR
REVERSE
MODE
ALL CD
EJECT
TAPE
CD
DISC 1 DISC 2 DISC 3
DISC
3
PLAY & EXCHANGE SYSTEM
COMPACT
DIGITAL AUDIO
DOLBY B NR
SET
ENTER
Cursor keys
CANCELMENU
ALL CD EJECT
3
7
CD
Main Tray
The Main Tray contains
disc trays for three CDs.
DISC 1 DISC 2 DISC 3
000
RDS
CONTROL
PLAY
MODE REPEAT CANCEL
SLEEP
DISC 3
DISC 2
DISC 1
FM MODE
MUTE
TAPE
DIRECTION
TAPE
DISPLAY
TV / VIDEO
L —
BALANCE
— R
TV SOUND
/ VCR
VCR
CONTORL
S. A. BASS
TAPE
TAPE
CONTROL
TUNER
SEA
CONTROL
CD
SEA
MODE
SURROUND
MODE
FADE
MUTING
REC
PAUSE
VOLUME
RM-SETD77RU REMOTE CONTROL
PTY SEARCH
PTY SELECT
+
PTY SELECT
–
R
D
S
D
I
S
P
L
A
Y
M
O
D
E
1 2 3
4 5 6
7 8 9
10
+10
SURROUND
CONTROL
EFFECT
LEVEL
REAR
LEVEL
DELAY
TEST
TONE
PRO
LOGIC DAP
CENTER
LEVEL
CENTER
MODE
PLAY MODE
REPEAT
CANCEL
Number keys
DISC 3
DISC 2
DISC 1
CD
3
¡ ¢
7
4 1
When the System is being used, the display shows other items as well.
However, we have only shown the items described in this section.
This illustration shows only the Menu display items for the CD.
Display
ON
OFF
SLEEP
TAPE
TIMER
DAILY
REC
CLOCK
SURROUND
SEA
DAP
TUNED STEREO
AUTO
[ TA NEWS INFO ]
1234
5678
9
10 11 12
1413 15 16
CD P. MODE
CONTINUE
PROGRAM
RANDOM
REPEAT
OFF
ALL
1CD
CD
=
TAPE
AUTO EDIT
SEA
CONTROL
kHz
MHz MEMORY
CH
VOL
Track number, Playing time, step number
All track numbers of the loaded CD
Menu display
CD
Press this to select the CD as the playback source. The button
indicator lights up and the 3 button, 7 button and the cursor
keys operate in CD control mode.
CD button
Press this button to select the CD as the playback source
and switch the Remote Control CD control mode.
DISC 1
Indicator
Disc display
CD indicator
Disc marker
