54 Setup
EXECUTE: Prnt Sc
F1
Quick
F2
Genrl
F3
Displ
F4
Kybd
F5
Keys
F6
Ports
F7
Host
F8
Print
F9
Emul
F10
Tabs
F11
AnsBk
F12
Prog
Print
Exec
Parameters
Save Terminal Recall Terminal Default Terminal
Save Session Recall Session Default Session
Reset Terminal Reset Session Reset Ports
Clear Screen Default Session UDKs
Choices
User Enter Key to Execute Action
Select
↑ → ↓ ← : Parameter
Enter/S-Enter : Next/Prev Choice Exit : Setup Key
All of the parameters in this menu are action parameters.
Terminal parameters affect all settings, including the emulation. Session choices affect
only settings that relate to the chosen session. In dual session (host) mode, there are two
independent sets of session parameters (Session 1 and Session 2). To toggle between
sessions, use the Ctrl-Enter (Num) keystroke.
Save Terminal: Save all settings in non-volatile (permanent) memory, including those
associated with the session selected.
Reset Terminal: All terminal parameters are initialized. It also performs reset pages
and default modes.
Recall Terminal: Revert to all terminal and session settings that were saved in
nonvolatile memory. A “Reset Terminal” is also performed. This is referred to as a
hard reset and is equivalent to turning the terminal off and back on.
Default Terminal: Load all defaults for the terminal and session, including the
emulation. A “Reset Terminal” is also performed.
Save Session: Save all the settings associated with the chosen session.
Reset Session: Initialize all session settings. This is also referred to as a “Soft-Reset.”
Perform page-resets and default modes. “Mode” specifies the parameters used by a
session which are not selectable through Setup such as Insert-Mode, Split-Screen, and
Graphics-Mode.
Recall Session: Load the previously saved settings associated with the chosen session.
A “Reset Session” is also performed.
Default Session: Load all defaults associated with the session selected.
Reset Ports: Clear the transmit buffers for the host and printer port, and receive buffer
for the host port. Unlocks the keyboard and clears its buffer data.
Clear Screen: Clear the screen and the entire page.
Default Session UDKS: Set the contents of all the function and edit keys associated
with the chosen session to their factory default states.
