26 Installation
SES1-EIA (DTE) SES2-AUX (DCE) PAR
DTE Serial
Printer**
Connection E:
Connect a null
modem adapter
between the serial
printer cable and
the EIA port.
Connection F:
Connect the serial
printer cable
directly to the
AUX port.
Connection G:
This is an option if
you connect a
parallel-to-serial
converter between
the serial printer
cable and the PAR
port.
Parallel Printer
(Centronics/
IBM)
Not applicable.
Not applicable.
Connection H:
Connect the parallel
printer cable to the
PAR port.
** Most serial printers are configured as DTE devices. The above connections
assume RS-232 configuration for the EIA port.
User Settings
Use the chart below to document your system and terminal settings:
Parameters Examples: Your Settings:
