32 Setup
QUICK: F1
F1
Quick
F2
Genrl
F3
Disp
F4
Kybd
F5
Keys
F6
Ports
F7
Host
F8
Print
F9
Emul
F10
Tabs
F11
AnsBk
F12
Prog
Print
Exec
Parameters
Emulation=IBM 3151 EIA Baud Rate=9600 EIA Data Format=8/1/N
Enhance=On Aux Baud Rate=9600 Aux Data Format=8/1/N
Comm Mode=Full Duplex Language=U.S. Sessions=One
Host/Printer=EIA/Para
Choices
ADDS VP Wyse 60 Wyse 50+ PC Term VT300/7 VT300/8 VT200/7
VT200/8 VT100 SCO Console IBM 3151 TVI 925 AT386
Select
↑ → ↓ ← : Parameter
Enter/S-Enter : Next/Prev Choice Exit : Setup Key
Emulation: [ADDS VP, Wyse 60, Wyse 50+, PC Term, VT300/8, VT300/7,
VT200/8, VT200/7, VT100, IBM 3151, SCO Console, AT386, TVI 925]
Select the “personality” of the terminal (the way in which it responds to commands).
Note that SCO Console and AT386 emulations are not available with the ANSI
keyboard. If you are using PC-Term emulation, refer to the Local Leadin selection in
the Keys: F5 section for access to local “hot keys.”
All associated defaults are loaded when the emulation is changed. Default choices
are in bold. Some defaults may vary depending on the selected emulation.
Comm Mode: [Full Duplex, Half Duplex, Full Block, Half Block]
Select the method of communication to match the host computer.
EIA Baud Rate: [110, 150, 300, 600, 1200, 1800, 2000, 2400, 4800, 9600,
19200, 38400, 57600, 76800, 115200, 134400]
Select the number of bits communicated per second to match the speed at which the
primary host or printer expects to communicate.
Aux Baud Rate: [110, 134.5, 150, 300, 600, 1200, 1800, 2000, 2400, 4800,
9600, 19200, 38400]
The speed at which the secondary host or printer expects to communicate.
