22 Installation
Common Setups
EIA PARAUX
TERMINAL
H
O
S
T
DTE
PARALLEL
PRINTER
B H
Sessions=One
Host/Printer=EIA/Para
EIA Baud, EIA Data Format, etc.
matches the host
EIA PARAUX
TERMINAL
H
O
S
T
O
N
E
DTE
A
H
O
S
T
T
W
O
DTE
B
Sessions=Two
Session1 Host/Printer=EIA/None
Session2 Host/Printer=Aux/None
EIA Baud, etc. matches host 1
Aux Baud, etc. matches host 2
SERIAL
PRINTER
F
MODEM
DCE
C
To
HOST
EIA PARAUX
TERMINAL
Sessions=One
Host/Printer=EIA/Aux
EIA/Baud, etc. matches the host
Aux Baud, etc. matches the printer
EIA Modem Control=On
PARALLEL
PRINTER
H
MODEM
DCE
C
To
HOST 1
EIA PARAUX
TERMINAL
MODEM
DCE
D
To
HOST 2
Sessions=Two
Session1 Host/Printer=EIA/Para
Session2 Host/Printer=Aux/Para
EIA Baud, etc. matches host 1
Aux Baud, etc. matches host 2
EIA Modem Control=On
Aux Modem Control=On
Host/Printer Connection Guide
CAUTION: Do not (un)plug in electrical storm.
