69
CDX-M620/M670
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C407 1-126-572-11 ELECT 4.7uF 20% 35V
C451 1-124-234-00 ELECT 22uF 20% 16V
C452 1-124-234-00 ELECT 22uF 20% 16V
C454 1-128-057-11 ELECT 330uF 20% 6.3V
C455 1-124-234-00 ELECT 22uF 20% 16V
C456 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C457 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C501 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(AEP,UK,E)
C501 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(US)
C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C505 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C506 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C507 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C508 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C509 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C511 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C512 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C513 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C514 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C515 1-124-584-00 ELECT 100uF 20% 10V
C516 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C517 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C602 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C603 1-126-934-11 ELECT 220uF 20% 16V
C650 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C651 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C652 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C653 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C655 1-124-589-11 ELECT 47uF 20% 16V
C656 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C657 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C658 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C659 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C660 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C701 1-124-589-11 ELECT 47uF 20% 16V
C703 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C704 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C705 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C706 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C707 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C708 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C709 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C710 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C711 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C712 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C813 1-115-156-11 CERAMIC CHIP 1uF 10V
C814 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-774-701-11 PIN, CONNECTOR 16P
* CN201 1-506-984-11 PIN, CONNECTOR (PC BOARD) 2P
* CN301 1-506-985-11 PIN, CONNECTOR (PC BOARD) 3P
CN401 1-764-617-12 PIN, CONNECTOR (PC BOARD) 30P
CN601 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
CN602 1-568-955-11 PIN, CONNECTOR 6P
CN603 1-563-614-31 CONNECTOR, FLEXIBLE 11P
CN604 1-815-499-21 CONNECTOR, FPC (ZIF) 18P
< JACK >
CN302 1-774-700-11 JACK, PIN 6P (BUS AUDIO IN,
AUDIO OUT REAR/FRONT)
< DIODE >
D101 8-719-055-30 DIODE D1FS4A-TA
D102 8-719-055-30 DIODE D1FS4A-TA
D104 8-719-801-78 DIODE 1SS184
D105 8-719-060-81 DIODE MA735-TX
D106 8-719-053-18 DIODE 1SR154-400TE-25
D107 8-719-422-62 DIODE MA8062-L-TX
D109 8-719-977-03 DIODE DTZ5.6B
D202 8-719-988-61 DIODE 1SS355TE-17
D203 8-719-422-41 DIODE MA8051-L-TX
D204 8-719-800-76 DIODE MA153-TX (AEP,UK,E)
D205 8-719-422-41 DIODE MA8051-L-TX (AEP,UK,E)
D301 8-719-074-47 DIODE CRS02(TE85L)
D302 8-719-074-47 DIODE CRS02(TE85L)
D303 8-719-074-47 DIODE CRS02(TE85L)
D304 8-719-074-47 DIODE CRS02(TE85L)
D305 8-719-074-47 DIODE CRS02(TE85L)
D306 8-719-074-47 DIODE CRS02(TE85L)
D307 8-719-074-47 DIODE CRS02(TE85L)
D308 8-719-074-47 DIODE CRS02(TE85L)
D309 8-719-801-78 DIODE 1SS184
D311 8-719-988-61 DIODE 1SS355TE-17
D401 8-719-049-38 DIODE 1N5404TU
D404 8-719-977-12 DIODE DTZ6.8B
D405 8-719-053-18 DIODE 1SR154-400TE-25
D406 8-719-053-18 DIODE 1SR154-400TE-25
D407 8-719-988-61 DIODE 1SS355TE-17
D501 8-719-988-61 DIODE 1SS355TE-17 (AEP,UK,E)
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-422-41 DIODE MA8051-L-TX
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-801-78 DIODE 1SS184
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D510 8-719-988-61 DIODE 1SS355TE-17
D511 8-719-988-61 DIODE 1SS355TE-17
