67
CDX-M620/M670
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
* A-3283-172-A MAIN BOARD, COMPLETE (M670:US)
* A-3283-173-A MAIN BOARD, COMPLETE (M620)
* A-3283-174-A MAIN BOARD, COMPLETE (AEP,UK,E)
*********************
* 3-019-565-01 BRACKET (IC)
* 3-230-509-01 CHASSIS, BACK
* 3-230-510-21 HEAT SINK (US)
* 3-230-510-31 HEAT SINK (AEP,UK,E)
* 3-230-513-01 HEAT SINK (REG)
7-685-792-09 SCREW +PTT 2.6X6 (S)
7-685-794-09 SCREW +PTT 2.6X10 (S)
< BUZZER >
BZ501 1-504-920-11 BUZZER
< CAPACITOR >
C51 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(M670:US)
C52 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(M670:US)
C53 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(M670:US)
C54 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(M670:US)
C55 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(M670:US)
C57 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C58 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C101 1-124-570-11 ELECT 220uF 20% 16V
C103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C107 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C108 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C109 1-126-176-11 ELECT 220uF 20% 10V
C110 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C113 1-126-176-11 ELECT 220uF 20% 10V
C115 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C116 1-126-176-11 ELECT 220uF 20% 10V
C117 1-126-176-11 ELECT 220uF 20% 10V
C118 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C119 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C121 1-128-057-11 ELECT 330uF 20% 6.3V
C122 1-110-654-11 DOUBLE LAYERS 0.047F 5.5V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C125 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C126 1-124-937-11 ELECT 10uF 20% 16V
C127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C128 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C201 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C207 1-124-589-11 ELECT 47uF 20% 16V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-104-942-11 ELECT 1uF 20% 50V
C210 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK,E)
C211 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AEP,UK,E)
C212 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK,E)
C213 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK,E)
C214 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(AEP,UK,E)
C215 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(AEP,UK,E)
C216 1-104-664-11 ELECT 47uF 20% 10V
(AEP,UK,E)
C217 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(AEP,UK,E)
C218 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK,E)
C219 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK,E)
C220 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
(AEP,UK,E)
C221 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
(AEP,UK,E)
C222 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(AEP,UK,E)
C223 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(AEP,UK,E)
C224 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK,E)
C225 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK,E)
C226 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP,UK,E)
C227 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(AEP,UK,E)
C228 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(AEP,UK,E)
C229 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
(AEP,UK,E)
C230 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(AEP,UK,E)
C231 1-124-233-11 ELECT 10uF 20% 16V
C301 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C302 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C303 1-136-154-00 FILM 0.012uF 5% 50V
C304 1-136-154-00 FILM 0.012uF 5% 50V
C305 1-124-233-11 ELECT 10uF 20% 16V
