61
CDX-M620/M670
252
254
253
259
251
257
255
255
258
264
264
265
266
256
263
261
260
262
267
#8
#8
#9
#8
#10
M903
C
C
5-6. CD MECHANISM SECTION (1)
(MG-383Z-121//K)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 251 1-676-709-11 DISC IN SW BOARD
252 3-040-039-01 CHASSIS (T)
253 3-040-038-01 SPRING (LR), TENSION
254 3-040-050-01 LEVER (L)
255 3-040-022-01 RETAINER (ROLLER), SHAFT
256 3-040-044-01 ROLLER (S)
257 3-040-067-01 LEVER (R)
258 A-3301-980-A SHAFT ROLLER ASSY
259 3-040-037-01 GUIDE (DISC)
260 3-040-040-01 ARM (ROLLER)
* 261 A-3294-809-A SERVO BOARD, COMPLETE
262 3-221-779-01 BRACKET (MOTOR)
263 3-040-034-01 SPRING (RA), TENSION
264 3-040-042-01 WASHER
265 3-043-880-01 RING (RA), RETAINING
266 3-044-206-11 SCREW, SPECIAL
267 3-231-392-01 PLATE (CD), SHIELD
M903 A-3315-039-A MOTOR SUB ASSY, LO (LOADING)
