62
CDX-M620/M670
304
301
306
307
308
310
312
311
309
302
302
302
303
313
307
D
D
314
305
not supplied
5-7. CD MECHANISM SECTION (2)
(MG-383Z-121//K)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
301 3-040-025-01 ARM, CHUCKING
302 3-040-031-01 DAMPER (T)
303 3-040-056-01 LEVER (D)
304 3-040-024-01 RETAINER (DISC)
305 3-040-054-01 WHEEL (LW), WORM
306 3-040-026-01 SPRING (CH), TENSION
307 3-040-032-01 SPRING (FL), COMPRESSION
308 3-040-033-01 SPRING (KF1), TENSION
309 A-3307-422-A CHASSIS (M) COMPLETE ASSY
310 3-040-059-01 SPRING (TR), TENSION
311 3-040-057-01 LEVER (LOCK)
312 3-040-058-01 GEAR (MDL)
313 3-040-052-01 WHEEL (U), WORM
314 3-040-051-01 LEVER (TR)
