65
CDX-M620/M670
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEYDISPLAY DISC IN SW
R72 1-216-811-11 METAL CHIP 150 5% 1/16W
R73 1-216-805-11 METAL CHIP 47 5% 1/16W
R74 1-216-864-11 SHORT 0
R76 1-216-841-11 METAL CHIP 47K 5% 1/16W
R77 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R78 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R79 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R80 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R81 1-216-817-11 METAL CHIP 470 5% 1/16W
R82 1-216-809-11 METAL CHIP 100 5% 1/16W
R83 1-216-809-11 METAL CHIP 100 5% 1/16W
R84 1-216-809-11 METAL CHIP 100 5% 1/16W
R85 1-216-841-11 METAL CHIP 47K 5% 1/16W
R86 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R87 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R88 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R89 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R90 1-216-809-11 METAL CHIP 100 5% 1/16W
R91 1-216-809-11 METAL CHIP 100 5% 1/16W
R92 1-216-809-11 METAL CHIP 100 5% 1/16W
R93 1-216-817-11 METAL CHIP 470 5% 1/16W
R94 1-216-864-11 SHORT 0
R95 1-216-846-11 METAL CHIP 120K 5% 1/16W
R96 1-216-850-11 METAL CHIP 270K 5% 1/16W
R97 1-216-033-00 METAL CHIP 220 5% 1/10W
< SWITCH >
S60 1-771-884-11 SWITCH, TACTILE (WITH LED) (RESET)
*************************************************************
* 1-676-709-11 DISC IN SW BOARD
****************
< SWITCH >
SW2 1-529-566-21 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-21 SWITCH, PUSH (1 KEY) (DISC IN)
*************************************************************
* A-3283-164-A KEY BOARD, COMPLETE (US)
* A-3283-176-A KEY BOARD, COMPLETE (AEP,UK,E)
********************
1-694-807-21 CONDUCTIVE BOARD, CONNECTION
1-694-808-21 CONDUCTIVE BOARD, CONNECTION
* 3-230-486-01 HOLDER (LCD-KEY)
* 3-230-487-01 PLATE (LCD-KEY), LIGHT GUIDE
* 3-230-488-01 SHEET (LCD-KEY), DIFFUSION
< CAPACITOR >
C1 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C6 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C7 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C8 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C9 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C10 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN1 1-815-499-21 CONNECTOR, FPC (ZIF) 18P
CN2 1-815-501-11 SOCKET, CONNECTOR 15P
< DIODE >
D7 8-719-422-41 DIODE MA8051-L-TX
D8 8-719-422-80 DIODE MA8075-H-TX
< IC >
IC1 8-759-653-26 IC LC75878W
< LIQUID CRYSTAL DISPLAY >
LCD1 1-804-349-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED1 8-719-079-26 LED NSSB440-WRST-THR (LCD BACK LIGHT)
LED2 8-719-079-26 LED NSSB440-WRST-THR (LCD BACK LIGHT)
LED3 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED4 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED5 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED6 8-719-078-39 LED CL-170SR-CD-T (RING ILLUMINATION)
LED7 8-719-078-39 LED CL-170SR-CD-T (CLOSE)
LED8 8-719-078-39 LED CL-170SR-CD-T (MODE)
LED9 8-719-078-39 LED CL-170SR-CD-T (Z)
LED10 8-719-078-39 LED CL-170SR-CD-T (OFF)
LED11 8-719-078-39 LED CL-170SR-CD-T (DSPL/PTY)
LED12 8-719-078-39 LED CL-170SR-CD-T (SCRL)
LED13 8-719-078-39 LED CL-170SR-CD-T (ENTER)
LED14 8-719-078-39 LED CL-170SR-CD-T (LIST)
LED15 8-719-078-39 LED CL-170SR-CD-T (MENU)
LED16 8-719-078-39 LED CL-170SR-CD-T (SOUND)
LED17 8-719-078-09 LED SLR-332CD-T32MN (DSO)
LED18 8-719-078-09 LED SLR-332CD-T32MN (EQ7)
< SWITCH >
LSW1 1-771-883-11 SWITCH, TACTILE (WITH LED) (–)
LSW2 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (SOURCE)
LSW5 1-771-883-11 SWITCH, TACTILE (WITH LED) (+)
LSW6 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (AF)
(AEP,UK,E)
LSW7 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (1/REP)
LSW8 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (2/SHUF)
LSW9 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (3)
LSW10 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (6)
LSW11 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (5)
LSW12 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (4)
LSW13 1-771-883-11 SWITCH, TACTILE (WITH LED) (. m)
