CDX-M620/M670
3-6. CAM (R)
3-5. ARM (A-R) ASSY, ARM (B-R) ASSY
1 Move the arm (B-R) assy in the direction of the
arrow A and the arm (A-R) assy in the direction of
the arrow B fully (full open state).
2 Align the hole (large) on the cam (R) with part C and
install the cam.
4 Turn the cam (R) clockwise and counterclockwise to
verify that both the arms are operated.
bracket (R) ass
y
3
arm (A-R) assy
2
stop ring 1.5, type-E
4
stop ring 1.5, type-E
1
arm (B-R) assy
3
stop ring 1.5, type-E
5
damper, oil
6
screw (P 2x4)
cam (R)
B
A
C
arm (B-R) assy
line
arm (A-R) assy
hole(large)
