Sony Ericsson BDV-E300 Home Theater System User Manual



Settings and Adjustments
81
GB
[Auto]: Outputs 1920 × 1080p/24 Hz video
signals only when connecting a 1080/24p-
compatible TV using the HDMI OUT jack.
[On]: Outputs 1920 × 1080p/24 Hz video
signals regardless of the connected TV type.
[Off]: Select this when your TV is not
compatible with 1080/24p video signals.
Note
• Video signals may not be output when [BD-ROM
1080/24p Output] is set to [On].
x [YCbCr/RGB (HDMI)]
You can set the color setting for video signals
output from the HDMI OUT jack. Select the
setting that matches the connected TV type.
[Auto]: Automatically detects the type of
external device, and switches to the matching
color setting.
[YCbCr (4:2:2)]: Outputs YCbCr 4:2:2 video
signals.
[YCbCr (4:4:4)]: Outputs YCbCr 4:4:4 video
signals.
[RGB (16-235)]: Select this when connecting to
a device with an HDCP-compliant DVI jack.
[RGB (0-255)]: Select this when connecting to
an RGB (0-255) device.
x [x.v.Colour Output]
Sets whether to send xvYCC information to the
connected TV.
Combining xvYCC-compatible video with a TV
that supports x.v.Colour display makes it
possible to more accurately reproduce object
colors present in the natural world.
[Auto]
: Normally select this.
[Off]: Select this when the picture is unstable or
colors appear unnatural.
x [Pause Mode] (BD/DVD VIDEO/DVD-R/
DVD-RW only)
You can select the picture in pause mode.
[Auto]: The picture, including subjects that
move dynamically, is output with no jitter.
Normally select this position.
[Frame]: The picture, including subjects that do
not move dynamically, is output in high
resolution.
[Audio Settings]
You can make the audio settings.
x [BD Audio Setting]
You can select whether to mix or not mix the
interactive audio (button sound, effect sound,
etc.) and secondary audio (commentary) when
playing a BD that contains such audio.
[Mix]: Outputs the audio obtained by mixing the
interactive audio and secondary audio to the
primary audio.
[Direct]: Outputs the primary audio only.
x [Audio DRC] (BD/DVD VIDEO only)
You can compress the dynamic range of the
sound track. [Audio DRC] is useful for watching
movies at low volume late at night.
[Auto]: Performs playback at the dynamic range
specified by the disc (BD-ROM only).
[Off]: No compression of dynamic range.
[On]: The system reproduces the sound track
with the kind of dynamic range that the
recording engineer intended.
x [Attenuate - TV]
Distortion may occur when you listen to a
component connected to the TV (AUDIO IN L/
R) jacks. You can prevent distortion by reducing
the input level on the unit. Distortion is not a
malfunction and will depend on the component
connected.
[On]
: Attenuates the input level. The output
level is changed.
[Off]: Normal input level.
