11 SOURCE : Press these buttons to toggle through the input
selections – Source 1, Source 2, Source 3, Source 4, iPod, Source 7, Front
Input, Media Player and Tuner. More Sources could be directly recalled
through these buttons upon enabling them at the Setup Menu (See the
section “SOURCE SETUP” at Setup Menu discussion).
12 LISTENING MODE: Use to step through the T 175’s Listening mode
as discussed on the section “LISTENING MODE”. Depending on the
format of the currently selected input (digital or analog, stereo or
multichannel), various listening modes are available.
13 TONE CONTROLS: Press to adjust TREBLE control using the VOLUME
knob over a + 10dB range. Press again to adjust BASS control and a
third time for DIALOG control. See also section about “TONE CONTROLS”
under “MAIN MENU” discussions.
14 TONE DEFEAT: Tone Controls are enabled or disabled by pressing this
button. Tone controls are bypassed at ‘Tone Defeat’ while at ‘Tone Active,’
the tone controls are enabled again. See also section about “TONE
CONTROLS” under “MAIN MENU” discussions.
15 FRONT INPUT/MP: Use this button to directly select Front Input and
Media Player. Toggle button to switch between Front Input and Media
Player input.
16 PHONES: Accepts stereo headphone using a standard 1/4-inch stereo
phone plug (use a suitable adapter for headphones equipped with a
smaller plug). Plugging in headphones will automatically switch the
T 175 to Stereo, Stereo Downmix or Analog Bypass modes.
17 FRONT INPUT jacks: Use these convenience jacks for occasional
sources such as a camcorder, tape player, video game console, any
analog audio or optical digital audio and composite or S-Video video
sources. If your source has a single audio out jack only or is marked
“Mono output”, plug this into the T 175’s Front “R (Mono)” input. On
the other hand, if your source has two output jacks indicative of stereo
output, insert both jacks into the T 175’s corresponding Front “L” and “R
(Mono)” input to achieve stereo output as well.
18 MP/MIC input: Connect your MP3’s standard stereo phone jack to
this input. This is the same input where Audyssey microphone jack is
connected (See also discussion about “AUDYSSEY AUTO CALIBRATION”.)
IDENTIFICATION OF CONTROLS
FRONT PANEL
8
